Woodford Carrington 5 Wood Burning / Multifuel Ecodesign Stove

  • In Stock | 48 Hour Delivery
Choose Delivery Date At Checkout
Special Price £749.00 Regular Price £900.00
(Price includes VAT and Delivery)
  • Heat Output: 5 kW
  • Efficiency: 82.50%
  • Energy Rating: A Plus
Product Options:
  • Specifications
    Guarantee Lifetime
    Efficiency 82.50%
    Heat Output 5 kW
    Energy Rating A Plus
    DEFRA Approved Yes
    Airwash System Yes
    Construction Steel Body - Cast Door
    Flue Outlet Top & Rear (Interchangeable)
    Flue Size 5-inch (125mm)
    Fuel Type Wood or Multi Fuel
    Fuel Grate Type Multifuel Grate (to burn Wood & Smokeless Coal)
    Suitable For 12mm Hearth Yes
    External Air Compatible Yes
    Distance to Combustibles - Sides 600 mm
    Distance to Combustibles - Rear 500 mm
    Sweep Flue through Stove? Yes
    Colour Black
    More Colours No
    Colour Options Blacks
    Finish Matt
  • Product Sizes
    Woodford Carrington 5 Wood Burning / Multifuel Ecodesign Stove
    Overall Width 430 mm
    Overall Height 602 mm
    Overall Depth 364 mm
    Rear to Centre of Top Flue (F) 104.5 mm
    Width to Centre of Top Flue (E) 215 mm
    Weight 71.4 Kg
  • Description

    At a glance

    • 5kW heat output
    • 82.5% efficiency rating
    • Robust steel body
    • Smooth cast iron door
    • Large viewing window
    • Multi-fuel capabilities

    Product information

    The Woodford Carrington 5 Wood Burning and Multifuel Stove delivers powerful and efficient heating along with durable construction and versatile functionality. As part of the Woodford Collection; its precision engineering and refined aesthetics make it an exceptional choice for any home.

    Outstanding performance

    With its 5kW output; the Carrington 5 provides ample warmth for standard room sizes; heating spaces quickly and evenly. It achieves an impressive 82.5% efficiency rating; ensuring you get the most from every fuel load while maintaining clean emissions. The large viewing window remains crystal clear thanks to the clean burn system; letting you enjoy mesmerising flames.

    Premium engineering and build

    The Carrington 5 features robust 16mm steel construction with solid castings; made to the highest manufacturing standards for long-lasting performance. Attention to detail is evident in the beautifully crafted cast-iron door; featuring inner chamfered edges. Sleek lines and a modern yet timeless design make it suitable for both classic and contemporary settings.

    Fuel flexibility and air control

    The multifuel capabilities and optimised air controls allow for outstanding versatility. The stove efficiently burns both wood and smokeless coal fuels. Separate primary and secondary air controls let you precisely regulate airflow and burn rate. This optimises efficiency; heat output; and emissions while providing options to match your needs.

    With its powerful heat output; exceptional efficiency; adaptable functionality; and durable yet beautiful design; the Woodford Carrington 5 Stove is the perfect centrepiece for creating a warm and welcoming focal point in any room.

    Features & benefits

    • Powerful 5kW Output: Provides ample warmth for standard room sizes without needing additional ventilation in most cases.
    • 82.5% Efficiency Rating: Ensures you get maximum heat from every fuel load; keeping energy usage efficient.
    • Crystal Clear Viewing Window: Lets you fully enjoy the ambience and beauty of the flames thanks to the clean burn system.
    • Smooth Cast Iron Door: Beautifully crafted with inner chamfered details for an elegant; durable focal point.
    • Multi-Fuel Capabilities: Accommodates both wood and smokeless coal with a built-in riddling grate and ash pan for convenience.
    • Interchangeable Flue Outlets: Allows for flexible installation in a variety of settings with top or rear outlet options.
  • Liner Pack & Stove Kits
    Direct Stoves - Stove Fitting Kits*
    What's included in the fitting kit
    • 1. Black stove pipe.
    • 2. A registration plate is used to seal the chimney opening off from the room preventing dust, soot, dirt and debris falling down the chimney. It also helps to prevent a draft coming down the chimney. We supply a standard 800mm x 400mm galvanised steel register plate with all our stoves. You will simply need to cut the plate to size to fit into your chimney opening.
    • 3. We also provide you with a single stove glove that you can use for stoking the fire and adding wood without the risk of personal injury.

    *Only available for wood, multifuel and gas stoves. Excluded for the following which do not need these items: inset stoves, electric stoves, flueless and balanced flue gas stoves and outdoor & garden products.

    Optional Extras.
    Carbon Monoxide Detector:

    Due to an update to Building Regulations it is now law to have a Carbon Monoxide alarm present in any room with a solid fuel appliance:- The Building Regulations 2000 Approved Document J (2010 Edition) '2.34 Where a new or replacement fixed solid fuel appliance is installed in the dwelling, a carbon monoxide alarm should be provided in the room where the appliance is located.'



    Flue Liner Packs:
    The flue liner pack consists of; a flue adaptor, which connects the stove pipe to the flexible flue liner, Dura Flue flexible flue liner (this will have a relevant diameter to the outlet size of the stove and 316 Grade) cut to the required length and a pot hanger rain cap, this supports the flue liner from the top of the chimney and also acts as a bird guard and rain cap.

    Stove Pipe with Door:
    A stove pipe with door or access point, allows the chimney to be swept through the pipe itself.

    Firewood Starter Bundle

    Our Firewood Starter Bundle contains all you need for your first fire in your new stove.
    1 box of kiln dried logs with a moisture content of less than 20% and Woodsure Ready to Burn certified.
    This is UK sourced wood from sustainable forestry. The wood is pine.
    1 bag of kindling and a pack of 20 natural wood eco firelighters.




    Please make the relevant selection above when placing your order if you require any of these parts and also select whether or not you require a Carbon Monoxide alarm sending out with your order. Please note that if these parts aren't selected with your order we can't send them for free after your order has been delivered.


  • Delivery Info

    Free 1 Man Delivery – For Full Details Please See Delivery Information

    Our "Free Delivery" is a one-man service. The goods will arrive on a lorry that is about the size of a fire engine. (Please let us know in advance if you have restricted access or other local issues that could affect delivery).

    The lorry has a tail lift that allows the driver to get the item(s) off the vehicle. The order will be packed and secured onto a pallet and the driver will have a pallet truck. He'll be able to wheel this as close as possible to your property. The pallet truck can only be wheeled over a finished surface so it's not possible to wheel it over a gravelled drive, steps, steep slopes for example. The pallets are normally about 1m wide so this is the minimum width gate they can fit through. Please note that the driver is not insured to unpack or carry the item(s) into your house.

    Fitting Kits and Liner Packs might arrive separately by courier delivery on the same day unless specified/requested in advance. An email confirmation will be sent if this is the case.

    If the goods are showing 48hr delivery, then this is the quickest time we're able to deliver these items (We do not deliver at weekends). You'll be asked to select a delivery date when purchasing the goods. Please note that if you live offshore these dates do not apply as it will take us slightly longer to get the goods to you and we will contact you directly.

    Please note that it is an all-day delivery service which is generally from 9 am – 6 pm Monday to Friday. Delivery Depots, if they have the facility, will text in advance but as the vans do multiple runs a day you might not receive a text until the afternoon if this service is available.

    Due to current pallet network pressures mainly due to driver shortages we cannot guarantee delivery on your chosen day but will do our best to communicate this as soon as we are made aware by the carriers.

    PLEASE NOTE THAT WE STRONGLY ADVISE THAT YOU DO NOT BOOK ANY CONTRACTORS, PLUMBER’S, OR FITTERS UNTIL YOU HAVE RECEIVED YOUR GOODS AS UNEXPECTED DELAYS CAN OCCUR.

  • FAQs
    Is the baffle a bolt in type
    Question by: John Mason on 7 Jun 2025, 12:47
    Hi John,

    Thanks for your question.

    The Woodford collection stoves typically hold the baffle in place with either a bolt or sleeve.

    We hope that this information helps
    Answer by: Jack on 9 Jun 2025, 16:37
