Fireline 5kW Wide Wood Burning / Multifuel Ecodesign Stove with Modern Door

£1,139.00
(Price includes VAT and Delivery)
  • Heat Output: 5 kW
  • Efficiency: 80.80%
  • Energy Rating: A Plus
Please select from the following product options:
  • Specifications
    Guarantee 7 Years
    Efficiency 80.80%
    Heat Output 5 kW
    clearSkies Rating clearSkies 5
    Energy Rating A Plus
    DEFRA Approved Yes
    Airwash System Yes
    Construction Steel Body - Cast Door
    Flue Outlet Top & Rear (Interchangeable)
    Flue Size 5-inch (125mm)
    Fuel Type Wood or Multi Fuel
    Fuel Grate Type Multifuel Grate (to burn Wood & Smokeless Coal)
    Suitable For 12mm Hearth Yes
    External Air Compatible Yes
    Distance to Combustibles - Sides 650 mm
    Distance to Combustibles - Rear 350 mm
    Sweep Flue through Stove? Yes
    Colour Black
    More Colours No
    Colour Options Blacks
    Finish Matt
  • Product Sizes
    Overall Width 440 mm
    Overall Height 569 mm
    Overall Depth 306 mm
    Rear to Centre of Top Flue (F) 81 mm
    Height to Centre of Rear Flue (D) 482 mm
    Weight 81 Kg
  • Description

    At a glance

    • Large glass provides excellent fire views
    • Curved cast iron door frame
    • Powerful air wash technology
    • Patented tertiary air system
    • Multifuel capable
    • Customisable handle options
    Product information

    The Fireline 5kW wide wood-burning and multifuel stove offers a modern twist on a classic heating solution. With its expansive glass viewing pane and curving cast iron door frame, this multifuel model provides an enticing platform for harnessing dancing flames. Optimised for clean burning and customisable style, the FQ5W brings innovation to fire.

    Captivating fireside views

    Central to the appeal of the FQ5W is its oversized, ceramic-glazed window. The subtle angles of the cast iron door frame maximise visibility of the firebox, creating a focal point for any room. Lit with logs or smokeless fuels, flickering flames are on full display for an inviting fireside experience.

    Intelligent air technologies

    Embedded air tubes drive the FQ5W's impressive performance. Powerful air wash flow keeps glass surfaces clear for unobstructed fire watching. Additionally, the stove utilises a patented tertiary air system to create a clean combustion, minimising emissions. This smart internal airflow makes for consistently clean-burning, environmentally conscious fires.

    Customised to you

    While visually stunning in standard form, the versatility of the FQ5W allows for added personalisation. Optional accessories like the stainless steel handle bar and log store stand let you tailor the stove's look and function to your space. Find the ideal finish that reflects your style.

    With its flair for grabbing attention coupled with intelligent design features, the Fireline 5kW wide brings innovation and customisation to real wood or smokeless fuel fires. Let flickering flames burn brightly through its expansive window and emanate a warmth that extends beyond physical comfort. The FQ5W is heating reimagined.

    Features & benefits
    • Large Viewing Area: The expansive ceramic-glazed window and curved cast iron frame provide an exceptional view of the dancing flames within the firebox.
    • Air Wash Technology: Powerful internal air tubes keep the glass clear for unobstructed fire watching.
    • Tertiary Air System: Patented combustion control creates a clean and efficient burn, reducing emissions.
    • Multi-Fuel Capability: Operates on both wood logs and smokeless fuel for versatility.
    • Customisation Options: Personalise with accessories like a stainless steel handle or log store stand to reflect your style.
    • Substantial Build: Durable cast iron body with 5kW output provides reliable heating power in a classic material.
  • Liner Pack & Stove Kits
    Direct Stoves - Stove Fitting Kits*
    What's included in the fitting kit
    • 1. Black stove pipe.
    • 2. A registration plate is used to seal the chimney opening off from the room preventing dust, soot, dirt and debris falling down the chimney. It also helps to prevent a draft coming down the chimney. We supply a standard 800mm x 400mm galvanised steel register plate with all our stoves. You will simply need to cut the plate to size to fit into your chimney opening.
    • 3. We also provide you with a single stove glove that you can use for stoking the fire and adding wood without the risk of personal injury.

    *Only available for wood, multifuel and gas stoves. Excluded for the following which do not need these items: inset stoves, electric stoves, flueless and balanced flue gas stoves and outdoor & garden products.

    Optional Extras.
    Carbon Monoxide Detector:

    Due to an update to Building Regulations it is now law to have a Carbon Monoxide alarm present in any room with a solid fuel appliance:- The Building Regulations 2000 Approved Document J (2010 Edition) '2.34 Where a new or replacement fixed solid fuel appliance is installed in the dwelling, a carbon monoxide alarm should be provided in the room where the appliance is located.'



    Flue Liner Packs:
    The flue liner pack consists of; a flue adaptor, which connects the stove pipe to the flexible flue liner, Dura Flue flexible flue liner (this will have a relevant diameter to the outlet size of the stove and 316 Grade) cut to the required length and a pot hanger rain cap, this supports the flue liner from the top of the chimney and also acts as a bird guard and rain cap.

    Stove Pipe with Door:
    A stove pipe with door or access point, allows the chimney to be swept through the pipe itself.

    Stove Glass Insurance:
    If you select to take out our stove glass insurance this covers your stove glass for the time period you select.
    If your glass breaks within that time period we will send you a replacement piece of glass regardless of the reason the glass broke. All we will ask is that you send a picture of the broken glass.
    The insurance only covers you for one replacement piece of glass. It doesn't cover you if you break the replacement piece of glass.
    All stove glass is covered during delivery and any glass broken in transit to you will be replaced free of charge, without affecting your stove glass insurance.

    Firewood Starter Bundle

    Our Firewood Starter Bundle contains all you need for your first fire in your new stove.
    1 box of kiln dried logs with a moisture content of less than 20% and Woodsure Ready to Burn certified.
    This is UK sourced wood from sustainable forestry. The wood is pine.
    1 bag of kindling and a pack of 20 natural wood eco firelighters.




    Please make the relevant selection above when placing your order if you require any of these parts and also select whether or not you require a Carbon Monoxide alarm sending out with your order. Please note that if these parts aren't selected with your order we can't send them for free after your order has been delivered.


  • Delivery Info

    Free 1 Man Delivery – For Full Details Please See Delivery Information

    Our "Free Delivery" is a one-man service. The goods will arrive on a lorry that is about the size of a fire engine. (Please let us know in advance if you have restricted access or other local issues that could affect delivery).

    The lorry has a tail lift that allows the driver to get the item(s) off the vehicle. The order will be packed and secured onto a pallet and the driver will have a pallet truck. He'll be able to wheel this as close as possible to your property. The pallet truck can only be wheeled over a finished surface so it's not possible to wheel it over a gravelled drive, steps, steep slopes for example. The pallets are normally about 1m wide so this is the minimum width gate they can fit through. Please note that the driver is not insured to unpack or carry the item(s) into your house.

    Fitting Kits and Liner Packs might arrive separately by courier delivery on the same day unless specified/requested in advance. An email confirmation will be sent if this is the case.

    If the goods are showing 48hr delivery, then this is the quickest time we're able to deliver these items (We do not deliver at weekends). You'll be asked to select a delivery date when purchasing the goods. Please note that if you live offshore these dates do not apply as it will take us slightly longer to get the goods to you and we will contact you directly.

    Please note that it is an all-day delivery service which is generally from 9 am – 6 pm Monday to Friday. Delivery Depots, if they have the facility, will text in advance but as the vans do multiple runs a day you might not receive a text until the afternoon if this service is available.

    Due to current pallet network pressures mainly due to driver shortages we cannot guarantee delivery on your chosen day but will do our best to communicate this as soon as we are made aware by the carriers.

    PLEASE NOTE THAT WE STRONGLY ADVISE THAT YOU DO NOT BOOK ANY CONTRACTORS, PLUMBER’S, OR FITTERS UNTIL YOU HAVE RECEIVED YOUR GOODS AS UNEXPECTED DELAYS CAN OCCUR.
