ACR Woodpecker WP5 Wood Burning / Multifuel Ecodesign Stove

  • In Stock | 48 Hour Delivery
Special Price £824.95 Regular Price £885.00
(Price includes VAT and Delivery)
  • Installation Available
Please select from the following product options:
Standard Black Handle
Woodpecker Additional Handle - Brushed Steel


The Woodpecker WP5 is the epitome of excellence in stove design. Crafted with the British home in mind, it boasts a simple yet elegant design that will fit seamlessly into any modern or traditional interior décor. The stove's outstanding quality and warmth are hard to beat, and with more than three decades of experience, the manufacturer is renowned for delivering on their promises.

Constructed with highly durable steel and cast iron, you can rest assured that this stove is built to last. The huge glass door offers an unobstructed view of the dancing flames inside, creating a warm and inviting atmosphere in any room.

But the Woodpecker WP5 isn't just a beautiful addition to your home; it's also an environmentally friendly choice. It's EcoDesign compliant and DEFRA-approved, meaning it meets all current emissions standards and can be used legally anywhere in the UK. With an energy efficiency rating of A+ at 82.5%, you can enjoy the warmth of this stove without worrying about the impact on the environment or your wallet.

The Woodpecker WP5 is also versatile, with the option of Direct Air, making it a perfect choice for new build installations. So whether you're looking to add a touch of elegance to your living room or keep your eco-footprint small, the Woodpecker WP5 is the perfect choice.

  • Outstanding quality and warmth
  • Simple yet elegant design
  • Highly durable steel and cast iron construction
  • Huge glass door for unobstructed view of flames
  • EcoDesign-ready and DEFRA-approved for environmentally friendly heating
  • A+ energy efficiency rating at 82.5%
  • Direct Air option for new build installations


Find the perfect stove for your home at our showrooms

Explore more wood-burning, electric, and gas stoves plus fires, fireplaces and fire surrounds at our Cheadle, Bromsgrove and Stockport showrooms.


Guarantee 5 Years
Efficiency 82.5%
Heat Output 5.0kW
Energy Rating A Plus
DEFRA Approved Yes
Airwash System Yes
Construction Steel Body - Cast Door
Flue Outlet Top & Rear (Interchangeable)
Flue Size 5-inch (125mm)
Fuel Type Wood or Multi Fuel
Fuel Type Multifuel Grate (to burn Wood & Smokeless Coal)
Log Length 400mm
Suitable For 12mm Hearth Yes
External Air Compatible Yes
More Colours No
Distance to Combustibles - Sides 600mm
Distance to Combustibles - Rear 450mm
Stove Range Woodpecker
Stove Window Size (Width mm x Height mm) 310mm x 378mm
Sweep Flue through Stove? Yes

Product Sizes

ACR Woodpecker WP5 Wood Burning / Multifuel Ecodesign Stove
Overall Width 420mm
Overall Height 550mm
Overall Depth 340mm
Rear to Centre of Top Flue (F) 110mm
Width to Centre of Top Flue (E) 210mm
Height to Centre of Rear Flue (D) 455mm

Liner Pack & Stove Kits

Direct Stoves - Stove Fitting Kits*
What's included in the fitting kit
  • 1. Black stove pipe.
  • 2. A registration plate is used to seal the chimney opening off from the room preventing dust, soot, dirt and debris falling down the chimney. It also helps to prevent a draft coming down the chimney. We supply a standard 800mm x 400mm galvanised steel register plate with all our stoves. You will simply need to cut the plate to size to fit into your chimney opening.
  • 3. We also provide you with a single stove glove that you can use for stoking the fire and adding wood without the risk of personal injury.

*Only available for wood, multifuel and gas stoves. Excluded for the following which do not need these items: inset stoves, electric stoves, flueless and balanced flue gas stoves and outdoor & garden products.

Optional Extras.
Carbon Monoxide Detector:

Due to an update to Building Regulations it is now law to have a Carbon Monoxide alarm present in any room with a solid fuel appliance:- The Building Regulations 2000 Approved Document J (2010 Edition) '2.34 Where a new or replacement fixed solid fuel appliance is installed in the dwelling, a carbon monoxide alarm should be provided in the room where the appliance is located.'

Flue Liner Packs:
The flue liner pack consists of; a flue adaptor, which connects the stove pipe to the flexible flue liner, Dura Flue flexible flue liner (this will have a relevant diameter to the outlet size of the stove and 316 Grade) cut to the required length and a pot hanger rain cap, this supports the flue liner from the top of the chimney and also acts as a bird guard and rain cap.

Stove Pipe with Door:
A stove pipe with door or access point, allows the chimney to be swept through the pipe itself.

Stove Glass Insurance:
If you select to take out our stove glass insurance this covers your stove glass for the time period you select.
If your glass breaks within that time period we will send you a replacement piece of glass regardless of the reason the glass broke. All we will ask is that you send a picture of the broken glass.
The insurance only covers you for one replacement piece of glass. It doesn't cover you if you break the replacement piece of glass.
All stove glass is covered during delivery and any glass broken in transit to you will be replaced free of charge, without affecting your stove glass insurance.

Firewood Starter Bundle

Our Firewood Starter Bundle contains all you need for your first fire in your new stove.
1 box of kiln dried logs with a moisture content of less than 20% and Woodsure Ready to Burn certified.
This is UK sourced wood from sustainable forestry. The wood is pine.
1 bag of kindling and a pack of 20 natural wood eco firelighters.

Please make the relevant selection above when placing your order if you require any of these parts and also select whether or not you require a Carbon Monoxide alarm sending out with your order. Please note that if these parts aren't selected with your order we can't send them for free after your order has been delivered.


Product Questions 4


Is there air control to the stove i.e can you let more air in when you want a flame and turn down when you dont?


Question by: James Sanderson on 4 Nov 2022, 16:42

Thank you for your enquiry.

This stove does have air controls underneath the door. It has a primary air control which is on the left side, and a secondary air control which is on the right hand side.

In a nut shell :Primary is the control that feeds the fire.

Secondary is the air wash to keep the glass clean.

Hope this helps
Answer by: Damian Todd (Admin) on 29 Nov 2022, 16:40
What is the required distance from the stove side/back to non combustable walls
Question by: david myler on 6 Mar 2021, 16:19
Hi there David, thanks very much for getting in touch. So, what I have done is add the User Guide to this model which you can find in the "downloads" section which gives all the info needed around this. What it says in the guide is this:

"The Woodpecker range of stoves can be recessed into a suitably sized, noncombustible fireplace or stood close to non-combustible materials. However a permanent free air gap of at least 50mm is recommended to be left at each side, 50mm above and at least 50mm at the back of the stove to obtain reasonable heat output and for access to the stove for removal, maintenance and servicing. A clearance of 150mm to each side will give a better heat output and facilitate any remedial works to be undertaken."

I hope this helps!
Answer by: Henry Lewis on 10 Mar 2021, 10:19
Please advise the weight of this stove please
Question by: Barbara Skaife on 5 Mar 2021, 12:55
Hi Barbara, this Stove weighs 70kg. Thanks.
Answer by: Henry Lewis on 9 Mar 2021, 15:39
Can you please tell me if this stove is suitable for use outdoors and would it rust. Can it be purchased with the log store to go beneath the stove?finally is it possible to get 2 metres of flu with the stove?

Thanks Mark
Question by: Mark chambers on 2 Feb 2021, 22:51
Hi Mark, thanks for getting in touch. It's not made to go outside and will rust.

Some outdoor stove suggestions can be found here -

The log store version of the Woodpecker can be found here -

You can get 2 metres of flue, but you need to make sure it's been used in a twin wall insulated chimney space. I hope this helps.
Answer by: Henry Lewis on 4 Feb 2021, 12:16
